Cutler-Hammer
503 Type M - 8", 10", 14", 18", 21", 24", 30"
505 D-C - 8", 10", 13", 16", 19", 23", 30"


No. 503 24" Type "M" Brake
No. 503 24" Type "M" Brake

Item
OEM Part
Description

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
20
21
22
23
24
25
26
27
28
29
30
31
32
33

29-473
929-802
913-888
624-492
913-887
29-471
29-471
51-214
969-434
915-2142Z
15-154
69-711
915-2141Z
48-322
48-338-16
61-140-3
624-433
913-948
873-12
Magnet Coil
69-493
915-1561Z
914-738
3679-92F1
49-2287
29-471
11-356
915-1562Z
17-714-2
929-802
929-800
913-880

Base Bushing
Bushing
Pin (For Shoe Lever)
Shoe Lever w/ Bushings
Pin (For Brake Shoe)
Bushings
Bushings
Plug for Aligning Brake Shoe
Spring in Brake Shoe
Lock Nut
Nut
Spring for Pull Rod
Nut
Brake Shoes w/ Lining Assembled
Brake Lining
Pull Rod
Armature Lever w/ Bushings
Pin (For Pull Rod)
Coil Shield

Main Spring
Nut
Stud
Spring Support
Spring Gland
Bushings
Adjusting Screw
Nut
Base
Bushings
Armature Bushings (Base)
Pin (For Armature)
